DH ROBOTICS SERVO ELECTRIC GRIPPER PGE SERIES – PGE-2-12 Slim-type Electric Parallel Gripper

Short Description:

The PGE series is an industrial slim-type electric parallel gripper. With its precise force control, compact size and highly working speed, it has become a “Hot sell product” in the field of industrial electric gripper.


  • Gripping Force: 0.8~2N
  • Recommended workpiece weight: 0.05kg
  • Stroke: 12mm
  • Opening/closing time: 0.15s
  • IP Class: IP40
  • Product Detail

    Product Tags

    Main Category

    Industrial robot arm /Collaborative robot arm / Electric gripper/Intelligent actuator/Automation solutions

    Application

    The PGE series is an industrial slim-type electric parallel gripper. With its precise force control, compact size and highly working speed, it has become a “Hot sell product” in the field of industrial electric gripper.

    PGE electric gripper application

    Feature

    PGE-2-12 Slim-type Electric Parallel Gripper

    ✔ Integrated design

    ✔ Adjustable parameters

    ✔ Intelligent feedback

    ✔ Replaceable Fingertip

    ✔ IP40

    ✔ -30℃ low temperature operation

    ✔ CE certification

    ✔ FCC certification

    ✔ RoHs certification

    Small size | Flexible installation

    The thinnest size is 18 mm with compact structure, supports at least five flexible installation methods to meet the needs of clamping tasks & saves design space.

    High Working Speed

    The fastest opening and closing time can reach 0.2 s / 0.2 s, which can meet the high-speed and stable clamping requirements of the production line.

    Precise Force Control

    With special driver design and driving algorithm compensation, the gripping force is continuously adjustable, and the force repeatability could reach 0.1 N

    Specification Parameter

    Product Parameters

    PGE-2-12 PGE-5-26 PGE-8-14 PGE-15-10 PGE-15-26 PGE-50-26 PGE-50-40 PGE-100-26
    Gripping force (per jaw) 0.8~2 N 0.8~5 N 2~8 N 6~15 N 6~15 N 15~50 N 15-50 N 30~50 N
    Stroke 12 mm 26 mm 14 mm 10 mm 26 mm 26 mm 40 mm 26 mm
    Recommended workpiece weight 0.05 kg 0.1 kg 0.1 kg 0.25 kg 0.25 kg 1 kg 1 kg 2 kg
    Opening/Closing time 0.15 s/0.15 s 0.3 s/0.3 s 0.3 s/0.3 s 0.3 s/0.3 s 0.5 s/0.5 s 0.45 s/0.45 s 0.6 s/0.6 s 0.5 s/0.5 s
    Repeat accuracy (position) ± 0.02 mm ± 0.02 mm ± 0.02 mm ± 0.02 mm ± 0.02 mm ± 0.02 mm ± 0.02 mm ± 0.02 mm
    Noise emission < 50 dB
    Weight 0.15 kg 0.4 kg 0.4 kg 0.155 kg 0.33 kg 0.4 kg 0.4 kg 0.55 kg
    Driving method Rack and pinion + Cross roller guide Rack and pinion + Cross roller guide Rack and pinion + Linear guide Precision planetary reducer + Rack and pinion Precision planetary reducer + Rack and pinion Precision planetary reducer + Rack and pinion Precision planetary reducer + Rack and pinion Precision planetary reducer + Rack and pinion
    Size 65 mm x 39 mm x 18mm 95 mm x 55 mm x 26 mm (without brake)
    113.5 mm x 55 mm x 26 mm (with brake)
    97 mm x 62 mm x 31 mm 89 mm x 30 mm x 18 mm 86.5 mm x 55 mm x 26 mm (without brake)
    107.5 mm x 55 mm x 26 mm (with brake)
    97 mm x 55 mm x 29 mm (without brake)
    118 mm x 55 mm x 29 mm (with brake)
    97 mm x 55 mm x 29 mm (without brake)
    118 mm x 55 mm x 29 mm (with brake)
    125 mm x 57 mm x 30 mm
    Communication interface Standard: Modbus RTU (RS485), Digital I/O
    Optional: TCP/IP, USB2.0, CAN2.0A, PROFINET, EtherCAT
    Rated voltage 24 V DC ± 10% 24 V DC ± 10% 24 V DC ± 10% 24 V DC ± 10% 24 V DC ± 10% 24 V DC ± 10% 24 V DC ± 10% 24 V DC ± 10%
    Rated current 0.2 A 0.4 A 0.4 A 0.1 A 0.25 A 0.25 A 0.25 A 0.3 A
    Peak current 0.5 A 0.7 A 0.7 A 0.22 A 0.5 A 0.5 A 0.5 A 1.2 A
    IP class IP 40 IP 40 IP 40 IP 40 IP 40 IP 40 IP 40 IP 40
    Recommended environment 0~40°C, under 85% RH
    Certification CE,FCC,RoHS
