Machine Tending

The Mobile Manipulator For CNC Higher precision load and unload

The customer needs

Use mobile cobot to replace human being to load, unload and transport the parts in workshop, even working 24 hours, which aims to improve productivity and relief increasingly employment pressure.

Why need Cobot do this job

1. It is a very monotonous Job, and this is not meaning that the workers salary is lower, as they would need to know how to operate the sorts of CNC machines

2. Less workers in the shop and improve productivity

3. Cobot is safer than industrial robot, can be mobile anywhere via. AMR/AGV

4. Flexible deployment

5. Easy to understand and operate

Solutions

By the customer needs in details, we offer a cobot with on-board vision set up on a AMR of laser guide, the AMR would transport the cobot close to the CNC unit. AMR stops, the cobot will shot the landmark on the CNC body firstly to acquire accurate coordinate information, then the cobot will go to the place where exactly locates in CNC machine to pick up or sending the part.

Stong points

1. Due to AMR travel and stop accuracy normally is not good, like 5-10mm,thus only depending on the AMR working precision definitely can not meet the entire and final operation of load and unload precision

2. Our cobot could meet the precision by landmark technology to reach the final Combined accuracy for load and unload at 0.1-0.2mm

3. You shall not need extra expense, energy to develop a vision system for this job.

4. Can realize to keep your workshop 24 hours running with some positions.

Soution Features

（Advantages of Collaborative Robots in CNC loading and unloading）

Precision and Quality

With high-precision grasping and handling capabilities, robots can avoid errors and damage caused by manual operations, ensuring the machining accuracy and quality stability of products and significantly reducing scrap rates.

Enhanced Efficiency

Composite robots can operate 24/7, with fast and precise loading and unloading capabilities. This greatly reduces the processing cycle for individual parts and effectively increases machine utilization.

Strong Safety and Reliability

Composite robots are equipped with intelligent obstacle avoidance and pedestrian detection functions, ensuring safety during the production process. They also have a high success rate for placement and stable operation.

High Flexibility and Adaptability

Composite robots can quickly adapt to the loading and unloading needs of different sizes, shapes, and weights of workpieces through programming. They can also be integrated with various types of CNC machines to meet diverse production requirements.

Cost - effectiveness

Although the initial investment is relatively high, in the long run, composite robots can reduce labor costs and minimize losses from rework and scrap due to defects. Overall operating costs are effectively controlled.

Substantial Reduction in Labor Costs

By introducing composite robots, the need for multiple workers to perform loading and unloading tasks is reduced. Only a few technicians are required for monitoring and maintenance, leading to significant labor cost savings.

Related Products

TM-14

    • Max. Payload: 14KG
    • Reach: 1100mm
    • Typical Speed: 1.1m/s
    • Max. Speed: 4m/s
    • Repeatability: ± 0.1mm
More Information

SJV-W1000

      • Max. Load Capacity: 1000kg
      • Comprehensive Battery Life: 6h
      • Positioning Accuracy: ±5, ±0.5mm
      • Rotation Diameter: 1344mm
      • Driving Speed: ≤1.67m/s
More Information
